How To Make a 18v Battery Charger Without Technical Knowledge
Today we will learn about how to make an 18v battery charger. Sometimes it happens that the 18v battery of one of our devices is not charged with the internal charger, then we need an external charger. With the help of which our battery can be charged.
We are also going to provide you a video in this article. If you are having any problem in making the charger, then you can make the charger by watching our video.
If you have to charge your battery with an external charge then you now have two options.
(1) First you can buy an 18v battery charger from the market. (2) Secondly, you can make an 18v battery charger at home.
But I will tell you about how to make an 18v battery charger at home. Before this, I will tell you about the components in the charger.
6 Electronic components are used to make 18v battery chargers.
(1) 0-12 volt, 2 Amp Transformer
(2) 220 Volts AC Input
(3) 1N5399 Diode
(4) 33k Resistance
(5) 1 Volt, Led
(6) 25 Volt, 3300uf Capacitor
Now you have come to know about the components used in it. Let us now make an 18v battery charger.
Make a 18v Battery Charger lithium battery
Step 1. First, we will add 220 Volts AC Input cable to both the wires of 0-12 volt, 2 Amp Transformer.
Step 2. Now we will add a 1N5399 Diode to the first wire of the output of the transformer and a second 1N5399 Diode to the second wire.
Step 3. Now connect both wires of the output of the transformer on both pins of 25 Volt, 3300uf Capacitor.
Step 4. Now add 33k Resistance on the minus (-) pin of the Capacitor.
Step 5. Now connect 1 Volt Led, to both pins of the Capacitor. (Note that one wire of the led must be connected to the minus (-) of the Capacitor and one wire to the Capacitor plus (+).
Step 6. Now take two wires, for output and add one wire to the plus (+) and the other to the minus (-).
Now your 18v battery charge is ready. If you have a multimeter, you can check the voltage of your charger. You will get Proper 18volt in the charger.
Answer. The 18v battery cannot be charged with the 12v charger. If you have to charge 18v battery then the voltage of the charger should be above 18v only then your battery will be charged.
Answer. The 20v battery cannot be charged with the 18v charger. If you have to charge a 20v battery then the voltage of the charger should be above 20v only then your battery will be charged.
